Specifications
- Stainless steel is nickel-bearing, 200 series minimum. This material is NSF recognized for corrosion resistance.
- Accommodates 10 or 20 each, 14" x 18" or 15" x 20" trays, end loaded one per ledge.
- Door opens a full 270 degrees for unobstructed access and contains a hold open device.
- Paddle door latch assures positive door closure.
- Recessed vertical push handles on both ends of the double component model and on the rear of the single compartment model.
- Cart body and removable stainless steel tray slides are easily cleaned and sanitized.
- Compartment floor drain facilitates interior cleaning.
- Perimeter bumper protects walls, furnishings and doors.
- Space saving narrow design.
- 18 gauge stainless steel body and doors.
- 16 gauge stainless tray slide with 14 gauge uprights.
- 16 gauge bottom and top.
- Please contact our facility at 615-895-5333 with inquiries for custom tray sizes, capacities, and ledge spacing.
- Double door pan door with 1" rigid fiberglass insulation for sound deadening.
- Floor drains.
Dimensions
| Model | Tray Capacity | Ledge Spacing | # of Interior Compart-ments |
Overall Size | Casters | Shipping Weight |
Case Cube | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| W | D | H | Type | Dia. | lbs. | Cu. ft. | |||||
| D10TCEL | 10 ea. | 14"x18" or 15"x20" | 5" |
1 | 30 1/2" | 26 1/4" | 60 3/4 " | 2 swivel, 2 fixed |
6" | 260 | 38.6 |
| D20TCEL | 20 ea. | 14"x18" or 15"x20" | 5" |
2 | 46" | 25" | 60 3/4 " | 4 swivel, 2 fixed |
6" | 415 | 50.7 |
Drawings
