Specifications
- Body, top, bottom and doors are made from 18 gauge stainless steel.
- Optional sloping top addition is made from 20 gauge stainless steel.
- Cabinet has five 1/4" thick clear tempered glass shelves with polished edges. S/S shelves are optional.
- Double pan door has 1/4" thick clear tempered glass that is sealed with weather stripping that holds glass in place securely.
- Doors have a 3-point locking latch system.
- Unit comes standard with 4" casters, two with brakes. Legs are optional.
- Counter-balance in back helps stablize unit when doors are open.
- Wall cabinets require field installation. Contact us for more information
- Some floor units may require field installation. Contact us for more information
Dimensions - Examples of Previous Models
| Model |
Overall Size |
Casters |
Shipping Weight |
| W |
D |
H |
Type |
Dia. |
lbs. |
| ASC-36 |
35 1/2" |
16" |
79" |
4 swivel, 2 w/brake |
4" |
335 |
| ASC-48 |
47 1/2" |
16" |
79" |
4 swivel, 2 w/brake |
4" |
450 |
| ASC-36-18 |
35 1/2" |
18" |
79" |
4 swivel, 2 w/brake |
4" |
360 |
| ASC-48-18 |
47 1/2" |
18" |
79" |
4 swivel, 2 w/brake |
4" |
470 |
| ASC-36-24 |
35 1/2" |
24" |
79" |
4 swivel, 2 w/brake |
4" |
400 |
| ASC-48-24 |
47 1/2" |
24" |
79" |
4 swivel, 2 w/brake |
4" |
520 |
